Descrizione


Accessori opzionali
* OBD2: €39 modulo per verifica e diagnostica avanzato
* USB DVR: €59 dispositivo per la registrazione video continua
* Car rear view camera: €49 retrocamera con visione notturna
* Scatola di DVB-T: €99 decoder digitale terrestre
* Scatola di DVB-T2: €129€ decoder digitale terrestre ad alta velocità
* Audio Digitale DAB+: €79 radio digitale DAB+ (copertura totale prevista nel corso degli anni)
* Funzione di TMPS: €89 modulo per verifica pressione pneumatici
VERSIONE SENZA LETTORE DVD
CHIP DSP INCLUSO
VIDEO INSTALLAZIONE QUI
Android 10 System
CPU: AC8227L Quad-core ARM Cortex-A7 4*1.5Ghz
2G DDR3 RAM Memory
Built In 16GB Inand Flash
CAPACTIVE 1024*600 Screen(For 7 Inch and Bigger Screen)
Built-in DSP Chip (Digital Signal Processing)
Mirror Link for Android Mobile+iPhone
1080P HD Video
Built-In WiFi Module
Support full Video output to sub-monitor like mirror link
External Microphone Included
Front and Rear Camera Can Work same time
ADAS Function (OPTIONAL)
Configuration | |
OS | Android 10 system |
CPU | AC8227L Quad-core ARM Cortex-A7 4*1.5Ghz |
RAM | DDR3 2GB |
Flash | Built in 16GB |
Touch Screen | Capacitive touch screen |
Radio IC | ST TDA7786 |
Amplify IC | ST TDA7388 |
Out Power | 4*45w |
Bluetooth Version | 4.0 |
Microphone | External Microphone |
DVD deck built-in | No |
SD Card Slot | 1 Channel |
USB Port | 1 Channel |
Max External Memory HDD | 128GB |
WIFI/3G | Built-In WiFi Module /Support External 3G Dongle |
4G | No |
Mirror link | Yes |
CANBUS | Yes |
Button Back Light | Red button light |
Display Screen | |
Video Decode Support | 1080P |
Resolution | 1024×600 |
Screen Dimension | 7 inch 16:9 |
Video & Audio | |
Video Input | 1-Channel RCA Input |
Video Output | 2-Channel RCA Output |
Audio Input | 2-Channel RCA Input |
Audio Output | 4.1Channel RCA Output |
Reverse Camera Input | Yes |
Other Functions | |
Pictrue In Pictrue | No |
Steering Wheel Control Function | Yes |
Carplay Dongle (USB Port) | Optional |
DVR Camera (USB Port) | Optional |
OBD Adaptor (Bluetooth) | Optional |
DAB+ Receiver (USB Port) | Optional |
TPMS Adaptor (USB Port) | Optional |
Informazioni aggiuntive
Marca | |
---|---|
Colore | |
Memoria RAM | |
GPS Integrato | |
Dimensioni schermo | |
Capacità di memoria | |
Unità di misura | |
Garanzia produttore | |
Descrizione dell'inserzione bundle | |
Inserzione bundle | |
Quantità | |
Modello | |
MPN | |
Porta | |
Formato compatibile | |
Funzioni | GPS, Navigatore, Lettore MP3, Equalizzatore, WiFi, Schermo Touch |
Sistema operativo | |
Marca veicolo | |
Caratteristiche | |
Dimensione | |
Canali | |
Modello veicolo compatibile | |
Modello processore |
